Installation
3-25 3000-A2-GA31-80 December 1994
Table 3-5
Carrier Address Assignment
Highest Existing Network Address *
First New Carrier Address
DATAPHONE II ADp
First New Carrier Address
011 – 048 01 – 32 2
051 – 088 33 – 64 3
091 – 28 65 – 96 4
131 – 68 97 – 128 5
171 – 208 129 – 160 6
211 – 248 161 – 192 7
251 – 288 193 – 224 8
291 – 328 225 – 256 **
* For the DMC protocol, the carrier address is automatically calculated by ANALYSIS 6510 if the DSU
software version is less than 4.25. When the DSU software version is 4.25 or greater, devices are
addressable independent of the carrier.
** It is recommended that you start a new control channel when the carrier address reaches this limit.
Table 3-6
Protocol DIP Switches
Switch
Protocol
Switch
DPII/ADp, CC * DPII/ADp, DC DMC
S1 – 4 — — —
S1 – 3 — — —
S1 – 2 Off ON ON or Off
S1 – 1 Off Off ON
* Factory default setting:
ON is to the left as you face the rear of the carrier.
Off is to the right.
