Equipment List
C-3 3000-A2-GA31-80 December 1994
Equipment Comcode
Feature/Part
Number
Network Adapter Cables 3
50-pin to eight 6-pin Modular Network Interface Adapter
(Canada Only)
50-pin to eight 8-pin Modular Network Interface (DSU/JM8
Lease) Adapter for Digital or Lease Lines
50-pin to eight 8-pin Modular Network Interface
(RJ45S/Programmable) Adapter
50-pin to eight 6-pin Modular Network Interface
(RJ11C/Permissive) Adapter
1.5
′
— 3000-F1-009
1.5
′
— 3600-F2-503
1.5
′
— 3600-F2-504
1.5
′
— 3600-F2-505
106459621
106303837
106459548
106459928
6-Port V.35 Interconnect Cable (26-pin/V.35) 1
′
— 3600-F3-500 106953508
Multiport Cables
TDM 60-pin Plug to five EIA-232 Socket Interface
Connectors for multiplexing and digital sharing
Digital Bridge 60-pin Plug to five EIA-232 Plug Interface
Connectors for multipoint dial backup
6
′
— 3600-F2-500
6
′
— 3600-F2-501
106314651
106315294
Telephone Cord 6-pin Modular
RJ11C/Permissive DDD (PSTN) Plug 7
′
— 4400-F1-531
25
′
— 4400-F1-533
106472913
106472921
Telephone Cord 8-pin Modular
RJ45S/Programmable DDD (PSTN) Plug 2.5
′
— 4400-F1-541
14
′
— 4400-F1-543
25
′
— 4400-F1-544
106472947
106472962
106472970
NMS 6-pin Modular Cable 3
′
— 4400-F1-510
10
′
— 4400-F1-511
25
′
— 4400-F1-512
106472830
106472848
106472855
NMS Adapter Cable/Diagnostic Extension 1.5
′
— 3000-F2-510 106768690
COMSPHERE 3000 Series Carrier, Installation Manual 3000-M3-001 —
COMSPHERE – 48 Vdc Central Office Power Unit,
Installation Manual 3000-A2-GB41 —
COMSPHERE 3550 Series Data Service Units, Models 3550
and 3551, User’s Guide 3550-A2-GB20 —
COMSPHERE 3600 Series Data Service Units, Models 3610
and 3611, Operator’s Guide 3600-M1-001 106314636
COMSPHERE 3600 Series Data Service Units, Models 3610
and 3611, Dial Backup Module and SNA Diagnostic Interface
Options, Applications Guide 3600-M1-002 064654461
C OMSPHERE 3600 Series Data Service Units, Models 3610
and 3611, Time Division Multiplexer, Multichannel Multipoint,
and Digital Bridge Options, Applications Guide
3600-M1-003 106465438
3 These adapter cables are extended using a 4400-F1-501/504 or 3000-F1-013/014 cable.
