Stacker parts list – Paxar 656 / 636 User Manual
Page 99
Users Manual Model 656/636
Assembly Drawings
• 93
Stacker Parts List
Item
Part
Number
Qty
Description
Item
Part
Number
Qty
Description
1
144034
1
Feed Lock Knob
23
358092
1
Roller, Stacker Assembly
2
184002
1
Thumb Screw Lock
24
358094
1
Roller, Stacker Support Assembly
3
188008
1
Stacker T-Nut
25
989979
1
10:32 x 1 Set Screw
4
358023
1
Knob Assembly
26
990006
2
4:40 x 1/4 Cap Screw
5
247035
1
Drive Pulley
27
990037
2
#6 SAE Washer
6
351160
1
Full Stacker Switch Harness
28
990042
4
8:32 x 3/16 Set Screw
7
351161
1
Stacker Motor Harnessed
29
990079
1
10:32 x 1/4 Cap Screw
8
358001
1
Stacker Support
30
990080
2
10:32 x 3/8 Cap Screw
9
358091
1
Stacker Base Assembly
31
990085
2
10:32 x 1-1/4 Cap Screw
10
358004
1
Stacker Lock
32
990090
1
10:32 x 3/8 Button Head
11
358006
1
Rail, Rear Stacker
33
990313
3
#10 Thumb Screw
12
358007
1
Rail, Front Stacker
34
990369
2
1/8” Collar
13
358008
2
Roller, Idler
35
990446
2
.188 x .500 x 8:32 Shoulder Screw
14
358010
1
Shaft, Roller
36
990450
2
.375 Round Spacer
15
358011
4
Pivot, Idler Roller
37
990641
2
6:32 Wing Nut
16
358012
1
Plate, Stacker Locator (not shown)
38
999044
2
.313 x .437 x .375 Flanged
Bushing
17
358013
1
Trip Rod
39
999100
4
3/16 x 5/16 x 1/8 Flanged Bearing
18
358015
2
Roller Support
40
990102
2
#10 SAE Washer
19
358016
1
Shaft, Roller
41
351125
1
Stacker Harness
20
358017
1
Spring, Trip Rod
42
990533
1
Tie Down
21
358018
1
1/5P 40T Timing Belt
43
990513
1
Wire Tie
22
358021
358019
15
15
O’Ring (long) “X” = 3.1875
O’Ring (short) “X” = 2.1875
44
358005
2
Pressure Roller
45
358020
1
Label Side Support
