Users Manual Model 656/636 Optional Stackers • 103
Optional 4.25” Stacker Parts List
Item Part # Description Qty Item Part # Description Qty
1 378205 Plate Stacker Support 1 17 990028 6-32 Flat Hd. Screw 4
2 378288 Rear Side Frame Assy 1 18 990079 10-32 Cap Screw 2
3 378289 Front Side Frame Assy 1 19 990313 #10 Thumb Screw Knob 4
4 378212 Drive Roller 1 20 990641 #6 Wing Nut 1
5 378214 Drive Shaft 1 21 990037 #6 Washer 1
6 378130 Rail Slide Bracket 2 22 990080 10-32 Cap Screw 2
7 378209 Mount Stacker Rail 1 23 990262 ¼” Snap Ring 1
8 378210 Base Stacker Rail 1 24 990019 6-32 Button Hd. Screw 2
9 38215 Stacker Upright Front 1 25 990369 1/8” Collar 2
10 378035 Stacker Upright Rear 1 26 184002 Web Guide Thumb Screw 1
11 378046 Belt Guard 1 27 351125 Stacker Harness (NS) 1
12 351161 Stacker Motor Harnessed 1 28 351160 Full Stacker Harn. (NS) 1
13 284022 Pulley Drive Belt 2 29 371133 Jam Sensor Harn. (NS) 1
14 188008 “T” Nut 4 30 358018 Timing Belt (NS) 1
15 990081 10-32 Cap Screw 2 31 990006 4-40 Cap Screw 2
16 990102 #10 Washer 2
