Users Manual Model 656/636

Assembly Drawings

• 77

Drive Parts List

Item

Part #

Description

Qty

1

196052 Idler Pulley Bushing

1

2

244024 Feed Knob/SS

1

3

354002 Bridge Plate, Web

1

4

354004 Bridge Blade, Lower

1

5

354008A Gear, Idler

1

6

354009A Gear, Driven

1

7

354014 Driven Roller, Molded

1

8

354017 Shaft, Idler Gear

1

9

354021 Eccentric Shaft

1

10

354092 Support, Rear Drive Assembly

1

11

354093 Support, Front Drive Assembly

1

12

354094 Roller, Drive Assembly

1

13

354095 Roller, Tape Assembly

1

14

355018 Support, Knife/Drive/Print

1

15

990023 6-32 x ½” Flat Head Screw

1

16

990090 10-32 x 3/8” Button Head Screw

4

17

990120 ¼-20 x ½” Cap Screw

5

18

990416 ¼-20 x ½” Flat Head Screw

1
