Users Manual Model 656/636

Optional Stackers

• 109

Optional Down Stacker Parts List (Part 3)

Item

Part #

Description

Qty

Item

Part #

Description

Qty

1

168084

Clutch Assy

1

17

991058

Spring

1

2

168013

Tamper Slide Block

1

18

990065

8-32 Button Hd. Screw

1

3

168012

Tamper Support

1

19

989978

#8 Star Washer

3

4

168034

Tamper Mount Bracket

1

20

990081

10-32 Cap Screw

2

5

168028

Tamper

2

21

990066 8-32 Button Hd. Screw

1

6

168036

Static Brush

1

22

990051 8-32 Cap Screw

6

7

168008

Tamper Link

1

23

990314 #8 Thumb Screw Cap

2

8

168085

Mounting Bracket Assy

1

24

990263 5/16 “E” Snap Ring

1

9

168016

Solenoid Mtg. Bracket

1

25

990325 3/16 “E” Snap Ring

1

10

168035

Spring Return Bracket

1

26

990067 #8 Washer

2

11

168038

Bracket Label Stop

1

27

990050 8-32 Cap Screw

2

12

168037

Rod Label Stop

1

28

990315 #10 Thumb Screw Cap

2

13

168006

Tamper Pivot Pin

1

29

990261 3/16 Snap Ring

2

14

188008

“T” Nut

2

30

990091 10-32 Button Hd. Screw

2

15

197315

Solenoid Actuator Arm

1

31

990066 8-32 Button Hd. Screw

5

16

168045

Stand-off Solenoid Arm

1

32

168032 Cover (Not Shown)

1
