Users Manual Model 656/636
Assembly Drawings
• 91
Knife Parts List
Item
Part
Number
Qty
Description
Item
Part
Number
Qty
Description
1
197003
1
#10 Washer
21
357019K
1
Clutch, Square Drive
2
197308
1
Adjuster, Knife
22
357018
1
Knife Guard
3
197311
1
Cam, Knife Homing
23
357091
1
Bracket, Inner Knife Assembly
4
197312
1
Spring, Cam
24
357092
1
Bracket, Outer Knife Assembly
5
197313
1
Plate, Spring Cam
25
357093
1
Knife, Stationary
6
357020
1
Actuator, Knife
26
357094
1
Knife Rotary
7
197317
1
Compression Spring
27
990016
2
6:32 x 3/8 Cap Screw
8
351123
1
Knife Solenoid Harness
28
990082
4
10:32 x 5/8 Cap Screw
9
517099
1
Knife Motor Assembly
29
990120
5
1/4:20 x 1/2 Cap Screw
10
354005
1
Upper Bridge Blade
30
990123
2
1/4:20 x 1 Cap Screw
11
354013
1
Molded Idler Roller
31
990102
2
#10 SAE Washer
12
355018
1
Support, Knife/Drive/Print
32
990261
1
3/16 Snap Ring
13
357003
1
Mount, Solenoid
33
990449
3
M3 x 6 Cap Screw
14
357021K
1
Adapter, Knife Motor
34
999055
1
8:32 x3/8 Flat Head
15
357005
1
Clutch Adapter w/ 8:32 x 1/4 SS
35
999099
2
3/16 x 5/16 x 1/4 Flanged Bushing
16
357006
1
Spring, Torsion Front (Natural
Finish)
36
989978
1
#8 Star Washer
17
357007
1
Spring, Torsion Rear (Red Finish)
37
990065
1
8:32 x 3/8 Button Head
18
357011
1
Static Brush
38
990066
4
8:32 x 1/4 Button Head
19
357013
1
Mount, Cam Stop
39
990019
1
6:32 x 1/4 Button Head
20
357016
1
Standoff, Solenoid Arm
40
990122
1
1/4:20 x 3/4 Flat Head
41
999097
1
Flanged Bushing (Inc. w/
357021k)
