Users Manual Model 656/636 Assembly Drawings • 81
Ink Unwind / Rewind Parts List
Item Part # Description Qty Item Part # Description Qty
1 356010 Shaft Lock 2 17 990251 1/8 x 1/2" Dowel Pin 1
2 990042 8-32 x 3/13" Set Screw 2 18 990133 1/4-20 x 3/4" Flat Head Screw 1
3 990490 Spring 2 19 990122 1/4-20 x 3/4" Cap Screw 1
4 999009 5/16" Thrust Bearing 2 20 376016 Bearing Housing 1
5 356053 Unwind Shaft 1 21 999002 Bearing 2
6 376087 Arbor Assembly 1 22 376023 Bearing Spacer 1
7 376003 Ink Arbor Guide 2 23 376025 Bearing Spacer 1
8 516113 Ink Guide 1 24 991018 Internal Snap Ring 1
9 376088 Arbor Unwind Assembly 1 25 376024 Bearing Spacer 1
10 990083 10-32 x 3/4" Cap Screw 1 26 990019 6-32 x 1/4" Button Head Screw 4
11 990313 #10 Thumb Cap 1 27 376022 Sprocket Altered 1
12 376026 Unwind Fiber Spacer 1 28 376014 Adapter Ink Sprocket 1
13 356016 Shaft, Foil Bracket 1 29 990102 #10 SAE Washer 1
14 376048 Disc Brake 1 30 990091 10-32 x 1/2" Button Head Screw 1
15 376017 Hub Rewind 1 31 990058 8-32 x 1/4" Set Screw 1
16 376029 Shaft, Rewind 1
