107T5
GENERAL PRODUCT SPECIFICATION
Go to cover page
17" V30 GS4 107T5-71K CMTR
TYPE
: 107T51/00
BRAND
: PHILIPS
2003-01-07
Wayne Lin
2003-01-07
30
16
590
4.2
Image size (For preset modes only)
The dimensions of guaranteed display area to be measured along the picture center of
horizontal and vertical axis of the screen as listed below: (preset modes only, refer to fig. 1)
Width
: 306
± 3 mm
Height
: 230
± 3 mm
4.3
Image centering deviation (For preset modes only)
With respect to fig. 2, the target relationships are the following :
|A- B|
£ 5 mm
|C- D|
£ 5 mm
Note : This centering is adjustable by the end-user.
4.4
Picture shift control range (For preset modes only)
H-shift range :
± 10 mm min.
V-shift range :
± 10 mm min.
4.5
Picture tilt
With respect to Fig. 3, Tilt to be measured on extremes of center line from bezel.
|A- B|
:
£ 2 mm
4.6
Geometrical distortions (For preset modes only)
It is acceptable that pincushion, trapezoid, rhomboid,
rotation and various waves distortions must remain within
the limits of tolerance as in Fig. 4,
where A = B = 2.0 mm.
C = D = 2.0 mm.
The waviness of any vertical or horizontal shall be less than 1.0 mm over a 50 mm distance.
4.7
Image non-linearity (For preset modes only)
Apply cross-hatch pattern with
12 equal blocks along horizontal axis,
9 equal blocks along vertical axis. (see Fig. 1)
Overall :
£ 10 %
Adjacent :
£ 6 % (For 64kHz mode H £ 8 %)
X. max. - X. min.
H. non-linearity =
x 100%
X. Max.
Y. max. - Y. min.
V. non-linearity =
x 100%
Y. Max.
