52 107T5 GENERAL PRODUCT SPECIFICATION
Go to cover page
17" V30 GS4 107T5-71K CMTR
TYPE : 107T51/00
BRAND : PHILIPS
2003-01-07
Wayne Lin
2003-01-07
30 10 590
TABLE 12: 37.861KHz/72.809 Hz, 640 X 480, pixel=31.5MHz
Horizontal Vertical
Frame border = 0 Frame border = 0
Total size = 26.413 us Total size = 13.735 ms
Display size = 20.317 us Display size = 12.678 ms
Rear porch = 4.064 us Rear porch = 0.739 ms
Sync width = 1.270 us Sync width = 0.079 ms
Sync polarity = - Sync polarity = -
TABLE 13: 50.625 KHz/100.049 Hz, 640 X 480, pixel=40.5MHz
Horizontal Vertical
Frame border = 0 Frame border = 0
Total size = 19.752 us Total size = 9.995 ms
Display size = 15.802 us Display size = 9.481 ms
Rear porch = 1.975 us Rear porch = 0.435 ms
Sync width = 1.580 us Sync width = 0.059 ms
Sync. polarity = - Sync. polarity = -
TABLE 14: 37.927 KHz/85.039 Hz, 720 X 400, pixel=35.5 MHz
Horizontal Vertical
Frame border = 0 Frame border = 0
Total size = 26.366 us Total size = 11.759 ms
Display size = 20.282 us Display size = 10.546 ms
Rear porch = 3.042 us Rear porch = 1.107 ms
Sync width = 2.028 us Sync width = 0.079 ms
Sync. polarity = - Sync. polarity = +
TABLE 15: 37.879 KHz/60.317 Hz, 800 X 600, pixel=40MHz
Horizontal Vertical
Frame border = 0 Frame border = 0
Total size = 26.400 us Total size = 16.579 ms
Display size = 20.000 us Display size = 15.840 ms
Rear porch = 2.200 us Rear porch = 0.607 ms
Sync width = 3.200 us Sync width = 0.106 ms
Sync. polarity = + Sync. polarity = +
