8. Testing
8700-A2-GB20-40 May 2002 8-11
Telco-Initiated Tests
Hotwire 8777 Termination Units support Telco-initiated tests, as shown in the
following table.
Telco-Initiated Line Loopback
Hotwire 8777 Termination Units support line loopback, as specified in AT&T
TR 54016, AT&T TR 62411, and ANSI T1.403. A Telco-Initiated Line Loopback
loops the received signal on the DSX-1 interface back to the DSX-1 interface
without modification. Framing, CRC, and FDL bits are returned unaltered, and no
BPVs or other line coding errors are removed. DSL time slots mapped to the
DSX-1 port are sent all ones.
Telco-Initiated Payload Loopback
Hotwire 8777 Termination Units support payload loopback, as specified in AT&T
TR 54016 and ANSI T1.403. A Telco-initiated line loopback loops the received
signal on the DSX-1 interface back to the DSX-1 interface. Framing, CRC, and
FDL bits are regenerated at the point of the loopback, and BPVs are removed.
DSL time slots mapped to the DSX-1 port are sent all ones.
Activation and
Deactivation Line
Loopback Payload
Loopback Remote Line
Loopback
In-Band Signal Supported Not Applicable Not Supported
Bit-Oriented Supported Supported Supported
Message-Oriented Not Applicable Not Supported Not Applicable
CAP
DSL
Port DSX-1
Port
CAP T1
LIU
Framer Framer Transceiver
99-16252
All Ones Telco
CAP
DSL
Port DSX-1
Port
CAP T1
LIU
Framer Framer Transceiver
99-16253
All Ones Telco
