A. Configuration Options
8700-A2-GB20-40
May 2002
A-21
The following screen is displayed for Model 8779:
If any port Mode is DS0 Cross-connect, select Assign_DS0s for the Assign Time
Slots screen to be displayed.
Select Clear_All to change the Mode of all enabled ports to DS0 Cross-Connect.
All DSL port numbers and time slot assignments are cleared.
For information about the cross-connection system, see
.
main/config/xconnect_mode
Slot: 18 Model: 8779
CROSS-CONNECT MODE
Source Destination
G.703 MODE DSL
1 DS1 Bypass 1
2 DS1 Bypass 2
3 DS1 Bypass 3
4 DS1 Bypass 4
5 DS1 Bypass 5
6 DS1 Bypass 6
7 DS1 Bypass 7
8 DS1 Bypass 8
Assign_DS0s
--------------------------------------------------------------------------------
Ctrl-a to access these functions, ESC for previous menu MainMenu Exit
Save Clear_All
