C. Connector Pin Assignments

C-2

May 2002

8700-A2-GB20-40

Port 4

36

Data Out (Ring)

11

Data Out (Tip)

35

Data In (Tip)

10

Data In (Ring)

Port 5

39

Data Out (Ring)

14

Data Out (Tip)

38

Data In (Tip)

13

Data In (Ring)

Port 6

42

Data Out (Ring)

17

Data Out (Tip)

41

Data In (Tip)

16

Data In (Ring)

Port 7

45

Data Out (Ring)

20

Data Out (Tip)

44

Data In (Tip)

19

Data In (Ring)

Port 8

48

Data Out (Ring)

23

Data Out (Tip)

47

Data In (Tip)

22

Data In (Ring)

Table C-1.

Front Panel DTE Connector Pinouts (2 of 2)

DSX-1 or
G.703 Port

50-Pin
Connector
Pinout

Function
