A. Configuration Options
A-40
May 2002
8700-A2-GB20-40
The Cross Connect Mode screen appears.
5. Configure the G.703 port to be used for Inband Management to DS0
Cross-connect and save your changes.
6. Use the Inband Management Channel screen on the 8779 unit to configure
Inband Management. From the 8779 unit, follow this menu selection
sequence:
Main Menu
→
Configuration
→
Current Configuration
→
Management and Communication
→
Inband Management Channel
main/config/xConnect_mode
Slot: 18 Model: 8779
CROSS CONNECT MODE
Source Destination
G.703 MODE DSL
1 DS0 Cross-connect Unassigned
2 DS0 Cross-connect Unassigned
3 DS0 Cross-connect Unassigned
4 DS0 Cross-connect Unassigned
5 DS0 Cross-connect Unassigned
6 DS0 Cross-connect Unassigned
7 DS0 Cross-connect Unassigned
8 DS0 Cross-connect Unassigned
Assign_DS0s
--------------------------------------------------------------------------------
Ctrl-a to access these functions, ESC for previous menu MainMenu Exit
Save Clear_All
main/config/management/inband
Slot: 4 Model: 8779
INBAND MANAGEMENT CHANNEL
Inband Management Select: Enable
Inband Management Type: PPP
Inband Management Port: 1
Inband Management Time Slot: 1
-------------------------------------------------------------------------------
Ctrl-a to access these functions, ESC for previous menu MainMenu Exit
Save
