A. Configuration Options
A-6 May 2002 8700-A2-GB20-40
Table A-3. Payload Rates and DSL Line Rates for G.703
DSL Line
Rate (Kbps)
Voice Mode
G.703-to-G.703 Data Mode
G.703-to-G.703 Data Mode
G.703-to-EIA-530-A
Payload
Rate (Kbps) Time
Slots Payload
Rate (Kbps) Time
Slots
Possible
Payload
Rate (Kbps)*
Time
Slots
2064 1920 30 1984 31 1920, 1984,
2048
30,
31, 32
1552 1408 22 1472 23 1536 24
1040 896 14 960 15 960, 1024 15, 16
784 640 10 704 11 576, 640, 768 9, 10,
12
528 384 6 448 7 448, 512 7, 8
400 256 4 320 5 320, 384 5, 6
272 128 2 192 3 192, 256 3, 4
144 N/A N/A 64 1 64, 128 1, 2
* For firmware versions N2.03.05 and below, the payload rate is only selectable at a
DSL line rate of 144 Kbps, while all other rates default to the maximum, depending
on the DSL line rate selected.
