A. Configuration Options
A-20 May 2002 8700-A2-GB20-40
Setting Cross-Connect Mode
For Cross-Connect Mode configuration options for Model 8777, refer to Table A-9,
Cross-Connect Mode Options – Model 8777 . For Cross-Connect Mode
configuration options for Model 8779, refer to Table A-10, Cross-Connect Mode
Options – Model 8779 . To access the Set Cross-Connect Mode screen, follow this
menu selection sequence:
Main Menu
→
Configuration
→
Current Configuration
→
Cross-Connect
→
Set Cross-Connect Mode
The following screen is displayed for Model 8777:
main/config/xconnect_mode
Slot: 18 Model: 8777
CROSS-CONNECT MODE
DSX-1 Port MODE DSL Port
1 DS1 Bypass 1
2 DS1 Bypass 2
3 DS1 Bypass 3
4 DS1 Bypass 4
5 DS1 Bypass 5
6 DS1 Bypass 6
7 DS1 Bypass 7
8 DS1 Bypass 8
Assign_DS0s
--------------------------------------------------------------------------------
Ctrl-a to access these functions, ESC for previous menu MainMenu Exit
Save Clear_All
