A. Configuration Options
8700-A2-GB20-40
May 2002
A-37
Inband Management Channel (Model 8779)
To access the Inband Management Channel screen, follow this menu selection
sequence:
Main Menu
→
Configuration
→
Current Configuration
→
Management and Communication
→
Inband Management Channel
NOTE:
Inband Management Channel is only available for Model 8779 Termination
Units configured as an LTU.
main/config/management/inband
Slot: 4 Model: 8779
INBAND MANAGEMENT CHANNEL
Inband Management Select: Enable
Inband Management Type: PPP
Inband Management Port: 1
Inband Management Time Slot: 1
Inband Management DLCI: 16
Inband Management LMI: Standard
-------------------------------------------------------------------------------
Ctrl-a to access these functions, ESC for previous menu MainMenu Exit
Save
