Introduction

32

Model 3088 Series User Manual

2 • Configuration

S2-6 through S2-8: Line Type (Models 3088/K and 3088/T)
The RocketLink-G has two different line types, T1 and E1. T1 has three different settings, and E1 has five dif-
ferent settings.

Console

The 3088 offers a console command line interface. To access the console, use a VT100 emulator configured to
19,200 kbps, 1 stop bit, no parity, and XON-XOFF flow control. Log into the unit using the default pass-
word. No username will be needed.

Note

For software release 2.1.2, log in with the default password patton.
For software release 2.1.3, log in with the default password superuser.

Through the console, the following variables can be configured:

Password: The password used to login to the console.

Circuit ID: The circuit ID communicated to other units via EOC. EOC (Embedded Operations Channel)
is an out-of-band channel specified in the G.991.2 standard for SHDSL. We use standard EOC messages
for our remote loopback. The 3088 also supports proprietary EOC messages that allow a 3096RC to con-
figure it.

Clock Mode: The following options are available:

-

Internal: The internal oscillator in the 3088 provides the clock to both the serial/T1/E1 and
DSL interfaces.

-

Network: The T1/E1 interface provides the clock for the DSL interface (T1/E1 only).

OFF

OFF

Reserved

Table 19. S2-6 through S2-8 Line Type Settings

S2-6

S2-7

S2-8

Line Type

ON

ON

ON

T1-Unframed

a

a. For T1 operation, pass framing must be enabled (see Pass Framing param-

eter in

table 2

on page 20 for details).

OFF

ON

ON

T1-SuperFrame

a

ON

OFF

ON

T1-ExtendedSuperFrame

a

OFF

OFF

ON

E1-Unframed (G.703 Clear Channel)

ON

ON

OFF

E1-Structured (G.704)

OFF

ON

OFF

E1-CRC

ON

OFF

OFF

E1-Multiframe

OFF

OFF

OFF

E1-CRC Multiframe

Table 18. S2-4 and S2-5 Clock Mode Settings

S2-4

S2-5

Clock Mode

Description
