Introduction

24

Model 3088 Series User Manual

2 • Configuration

DIP switch settings for RocketLink-G models 3088/CA and 3088/D

An overview of the RocketLink-G DIP switch functions for Models 3088/CA and 3088/D is provided in

table 3

and

table 4

. The detailed switch settings are shown in following tables.

Table 3. Model 3088/CA and 3088/D - S1 DIP-Switch Functions

Position

Function

S1-1

Data Rate

S1-2
S1-3
S1-4
S1-5
S1-6
S1-7
S1-8

TX Clock

Table 4. Model 3088/CA and 3088/D - S2 DIP-Switch Functions

Position

Function

S2-1

Reserved

S2-2

Line Probe

S2-3

Annex

S2-4

Clock Mode

S2-5
S2-6

DTE Loops

S2-7

Reserved

S2-8
