2 • Configuration
S1-1 through S1-6: TimeSlots & Data Rate (RocketLink-G Models 3088/K and 3088/T)
Switches S1-1 through S1-6 define the number of timeslots utilized, and thus the data rate, on both the T1/E1
line and the DSL line. G.991.2 specifies G.SHDSL data rates beginning at 192 kbps. In compliance with the
G.991.2 specification, the RocketLink-G will only set the number of DSL timeslots at a value greater than or
equal to 3, regardless of the setting for T1/E1 timeslots
Table 14. S1-1 through S1-6 Timeslots & DSL Data Rate DIP switch settings
S1-1
S1-2
S1-3
S1-4
S1-5
S1-6
Number of Timeslots
Data Rate (kbps)
OFF
ON
ON
ON
ON
ON
1
64
ON
OFF
ON
ON
ON
ON
2
128
OFF
OFF
ON
ON
ON
ON
3
192
ON
ON
OFF
ON
ON
ON
4
256
OFF
ON
OFF
ON
ON
ON
5
320
ON
OFF
OFF
ON
ON
ON
6
384
OFF
OFF
OFF
ON
ON
ON
7
448
ON
ON
ON
OFF
ON
ON
8
512
OFF
ON
ON
OFF
ON
ON
9
576
ON
OFF
ON
OFF
ON
ON
10
640
OFF
OFF
ON
OFF
ON
ON
11
704
ON
ON
OFF
OFF
ON
ON
12
768
OFF
ON
OFF
OFF
ON
ON
13
832
ON
OFF
OFF
OFF
ON
ON
14
896
OFF
OFF
OFF
OFF
ON
ON
15
960
ON
ON
ON
ON
OFF
ON
16
1024
OFF
ON
ON
ON
OFF
ON
17
1088
ON
OFF
ON
ON
OFF
ON
18
1152
OFF
OFF
ON
ON
OFF
ON
19
1216
ON
ON
OFF
ON
OFF
ON
20
1280
OFF
ON
OFF
ON
OFF
ON
21
1344
ON
OFF
OFF
ON
OFF
ON
22
1408
OFF
OFF
OFF
ON
OFF
ON
23
1472
ON
ON
ON
OFF
OFF
ON
24
1536
OFF
ON
ON
OFF
OFF
ON
25
1600
ON
OFF
ON
OFF
OFF
ON
26
1664
OFF
OFF
ON
OFF
OFF
ON
27
1728
ON
ON
OFF
OFF
OFF
ON
28
1792
OFF
ON
OFF
OFF
OFF
ON
29
1856
ON
OFF
OFF
OFF
OFF
ON
30
1920
OFF
OFF
OFF
OFF
OFF
ON
31
1984
ON
ON
ON
ON
ON
OFF
32
2048
