Page 8
INSTALLATION
A-2
A-2
PIPELINER® 200D KUBOTA
TECHNICAL SPECIFICATIONS - PIPELINER® 200D KUBOTA (K6090-11)
INPUT - DIESEL ENGINE
RATED OUTPUT @ 104°F(40°C) - WELDER
HEIGHT
WIDTH
DEPTH
WEIGHT
45.50
(2)
in.
24.00 in.
68.00 in.
1302 lbs.
(1156 mm)
(610 mm)
(1727 mm)
(592 kg)
RATED OUTPUT @ 104°F(40°C) - GENERATOR
DESCRIPTION
RATED DC OUTPUT
Duty
DC CURRENT RANGE
VOLTS @ RATED AMPS
CYCLE
Fine Adjustments in each Range
200 Amp DC Welder
LINCOLN PLUS RATING 40V @ 200A
All Copper Windings
NEMA RATING 28V @ 200A
60%
40-300 Amps
Pure DC Power Generator
Auxiliary Power
(1)
1.75 kW 15 Amps @ 120V DC @ 35% Duty Cycle
PHYSICAL DIMENSIONS
(1) Output rating in watts is equivalent to volt-amperes at unity power factor. Output voltage is within ± 10% at all loads up to rated capacity.
When welding, available auxiliary power will be reduced.
(2) Height is to the top of exhaust elbow. Case height is 40.9 in.(1039mm).
Make/Model
Description
Speed (RPM)
Displacement
Starting
Capacities
System
4 Cylinder
4 Cycle
134.1 cu. in
12VDC battery
Fuel: 15 gal
Naturally Aspirated
(2.2 ltrs)
(Group 45, 650
57 L
Kubota
Water-Cooled
High Idle 1600
cold crank amps)
V2203M
Diesel Engine
Low Idle 1400
Bore x Stroke
1.4 KW Starter
Oil: 8.0 Qts.
Cast Iron Cylinder, Full Load 1600
40 A. Alternator
7.6 L
Block/Crankcase
3.43” x 3.64”
w/ built in reg.
9.5 Qts
.
27.8HP @1600 RPM
9.0 L
