Lincoln Electric PIPELINER 200 - Manual (Page 109)

ENGINE THROTTLE ADJUSTMENT TEST (CONTINUED)
(PERKINS ONLY)
PROCEDURE
6. If either of the readings is incorrect, adjust the throt-
tle as follows:
Adjust HIGH IDLE:
The Engine is Preset at factory. Contact Perkins
@ 1-888-737-5364 or www.perkins.com
Adjust LOW IDLE:
First make sure there is no load on the machine.
Set the IDLE switch to AUTO and wait for the
engine to change to low idle speed.
Use the 7/16” wrench to loosen the solenoid idle
rod locking nut. See Figures F.13 & F.14 Turn the
rod to change the amount of throw in the lever arm,
until the tach reads between 1375 and 1425 RPM.
Retighten the locking nut. Make sure the lever arm
does not contact low speed adjustment stop. Back
stop out if necessary.
TROUBLESHOOTING & REPAIR F-39 F-39
PIPELINER® 200
