Primary control module, Secondary smart touch control module, Smart touch – Lochinvar ArmorX2 1.5 User Manual
Page 7: Service
LOW VOLTAGE
CONNECTION
BOARD
PRIMARY
CONTROL MODULE
ALARM BELL
RUN TIME CONTACTS
SEQUENCER / BUILDING
MANAGEMENT SYSTEM
HEAT EXCHANGER 1 /
HEAT EXCHANGER 2
HW PUMP
IGNITOR
BLOWER
GAS VALVE
PC INTERFACE
SECONDARY
SMART TOUCH
CONTROL MODULE
TOUCH PANEL
INTERFACE
TOUCH DISPLAY
SMART TOUCH
Control outputs
1
Service
(continued)
7
Service Manual
