Kawasaki STX-15F User Manual
Page 415
APPENDIX 16-13
Cable, Wire and Hose Routing
1. Right Rear Duct
2. Right Bilge Hose
3. Left Bilge Hose
4. Left Rear Duct
5. Left Water Box Muffler
6. Position the left rear duct inside the left bilge hose as shown.
7. Position the right rear duct under the right bilge hose as shown.
8. Right Water Box Muffler
9. Right Bilge Breather
10. Left Bilge Breather
11. Left Bilge Filter
12. Right Bilge Filter
