ENGINE TOP END 6-3
Exploded View
Torque
No. Fastener
N·m kgf·m ft·lb
Remarks
1 Air Suction Valve Cover Bolts 9.8 1.0 87 in·lb
2 Cylinder Head Cover Bolts 9.8 1.0 87 in·lb
3 Upper Camshaft Chain Guide Bolts 12 1.2 104 in·lb S
4 Camshaft Cap Bolts 12 1.2 104 in·lb S
5 Cylinder Head Bolts ( 7) 20 2.0 14 S
6 Cylinder Head Bolts ( 11) 23 2.3 17 First, MO, S
6 Cylinder Head Bolts ( 11) 59 6.0 43 Final, MO, S
7 Water Jacket Plugs 20 2.0 14 L
8 Cylinder Head Bolts ( 6) 12 1.2 104 in·lb S
9 Engine Hook Bolts 20 2.0 14
10 Camshaft Position Sensor Bolt 9.8 1.0 87 in·lb L
EO: Apply engine oil.
L: Apply a non-permanent locking agent.
MO: Apply molybdenum disulfide oil solution (mixture of the engine oil and molybdenum disulfide
grease in a weight ratio 10 : 1).
S: Follow the specific tightening sequence.
SS: Apply silicone sealant.
