PUMP AND IMPELLER 11-3
Exploded View
Torque
No.
Fastener
N·m
kgf·m
ft·lb
Remarks
1
Pump Bracket Mounting Bolts (2)
19
1.9
14
L, SS
2
Pump Bracket Mounting Bolts (4)
9.8
1.0
87 in·lb
L
3
Pump Mounting Bolts
36
3.7
27
L
4
Grate Mounting Bolts
9.8
1.0
87 in·lb
L
5
Pump Cover Mounting Bolts
7.9
0.80
69 in·lb
L
6
Impeller
98
10
72
7
Pump Cap Bolts
9.8
1.0
87 in·lb
L
8
Pump Outlet Mounting Bolts
19
1.9
14
L
9
Steering Nozzle Pivot Bolts
19
1.9
14
L
10 Pump Cap Plug
3.9
0.40
35 in·lb
11 Filter Cover Mounting Bolts
9.8
1.0
87 in·lb
L
12 Steering Cable Joint Bolt
9.8
1.0
87 in·lb
L
A: JT1500-A1 Model
B: JT1500-A2 Model
∼
HG: Apply high grade water resistance grease (Chevron: Black Pearl Grease EP NLGI 2 or equiva-
lent).
L: Apply a non-permanent locking agent.
M: Apply molybdenum disulfide grease.
SS: Apply silicone sealant.
