ENGINE TOP END 6-5
Exploded View
Torque
No.
Fastener
N·m
kgf·m
ft·lb
Remarks
1
Exhaust Side Camshaft Chain Guide Bolts (Upper)
25
2.5
18
2
Exhaust Side Camshaft Chain Guide Bolts (Lower)
12
1.2
104 in·lb
3
Upper Camshaft Chain Guide Bolts
12
1.2
104 in·lb
S
4
Inlet Side Camshaft Chain Guide Bolt
12
1.2
104 in·lb
L
5
Camshaft Chain Tensioner Mounting Bolts
9.8
1.0
87 in·lb
L
6
Camshaft Chain Tensioner Cap Bolt
20
2.0
14
7
Camshaft Position Sensor Rotor Bolt
12
1.2
104 in·lb
L
8
Water Hose Joint
11
1.1
95 in·lb
SS
9
Oil Passage Joint
11
1.1
95 in·lb
L
10. Closed coil end faces downward.
11. A marking hollow faces exhaust side.
EO: Apply engine oil.
G: Apply grease.
L: Apply a non-permanent locking agent.
M: Apply molybdenum disulfide grease.
MO: Apply molybdenum disulfide oil solution (mixture of the engine oil and molybdenum disulfide
grease in a weight ratio 10 : 1).
R: Replacement Parts
S: Follow the specific tightening sequence.
SS: Apply silicon sealant.
