Preparation section
11
Controls and indicators
*
1 Display
2 sound key %
Used for switching the EX.BASS play and LOUDNESS play.
3 AUX key ‡
Press to listen to the input source connected to AUX (analog
external).
4 TAPE 0 key *
Press to open or close the cassette holder.
5 Standby / timer indicator
Light in standby mode of power.
Red : Normal standby mode
Amber : Timer standby
Extinguished : Power ON mode
6 POWER(
) key (For U.S.A. and Canada)
$
(POWER) key (For other countries) $
7 Remote sensor #
8 TAPE EQ. key (
Press to switch the tape equalizer on.
9 o.t.e key
These keys are used for recording of a CD onto tapewith a
one-touch operation.
Press either key during CD playback to record the currently
played track onto tape. Press in stop mode to record the entire
CD onto tape.
›fi
0 CD 0 key ^
Press to open or close the CD tray.
! CD 6 key ^
Press to select the CD input and start CD playback.
Press during CD playback to let it pause temporarily.
@ phones jack %
Headphones with a stereo mini plug (optional) can be con-
nected.
# Cassette holder
Press the TAPE
0
key to open or close.
$ menu key
Press to switch the function of the volume/multi control
knob.
This key is also used when setting the time of the day.
°
% set/demo key
Press to set or enter an item selected with the volume/multi
control knob.
(fl
Used for demonstration ON/OFF.
0
^ Skip/search (4/ ¢) keys
During CD operation :
&
Press to skip tracks in the forward or backward direction.
During TAPE operation : (
Press to search in the forward or backward direction.
During TUNER operation : )
Used to select a preset station.
& volume/multi control knob !
Normally this is used for volume adjustment.
* TAPE rec key ∞
Press to start recording. Pressing the key during recording
stops it after leaving a non-recorded space (blank) of about 4
seconds.
(
TUNER/band key
)
The received broadcasting band is switched.
Press to select the TUNER input.
) 7STOP key
Press in power standby mode to display the clock.
¡ TAPE ` key *
Press to select the TAPE input and play a tape.
™ CD tray
Press the CD
0
key to open or close.
Turning the knob switches the display contents.
TAPE RVS. ?
(
AUTO PRESET (or A.MEMORY ? ) ™
(Only when the TUNER input is selected)
AUX INPUT
? ‡
(Only when the AUX input is selected)
BALANCE
?
fl
BACK LIGHT ?
9
A.P.S. SET ?
9
TIMER SET ? ·
÷ The function of the control knob returns to the normal
mode when it has not been operated for 20 seconds.
* About the volume/multi control knob
After selecting the function of this knob with the
menu
key, select the desired control item by turn-
ing the volume/multi control knob.
To set or enter the setting of the selected item,
press the
set/demo key.
menu
set/demo
down
volume/
multi control
up
