VLAN C
ONFIGURATION
3-163
Associating VLANs
Each community or isolated VLAN must be associated with a primary
VLAN.
Command Attributes
• Primary VLAN ID – ID of primary VLAN (1-4094).
• Association – Community or isolated VLANs associated with the
selected primary VLAN.
• Non-Association – Community or isolated VLANs not associated
with the selected primary VLAN.
Web – Click VLAN, Private VLAN, Association. Select the required
primary VLAN from the scroll-down box, highlight one or more
community VLANs in the Non-Association list box, and click Add to
associate these entries with the selected primary VLAN. (A community
VLAN can only be associated with one primary VLAN.)
Figure 3-69 Private VLAN Association
CLI – This example associates community VLANs 6 and 7 with primary
VLAN 5.
Console(config)#vlan database 4-198
Console(config-vlan)#private-vlan 5 association 6 4-211
Console(config-vlan)#private-vlan 5 association 7 4-211
Console(config-vlan)#
