SMC Networks TigerSwitch User Manual
Management guide
TigerSwitch 10/100
24-Port 10/100Mbps
Stackable Managed Switch
Management Guide
◆ 24 auto-MDI/MDI-X 10BASE-T/100BASE-TX ports
◆ 2 Gigabit RJ-45 ports shared with 2 SFP transceiver slots
◆ 2 Gigabit stacking ports that act as Ethernet ports in
standalone mode
◆ Stacks up to 8 units
◆ 12.8 Gbps of aggregate bandwidth
◆ Non-blocking switching architecture
◆ Spanning Tree Protocol and Rapid STP
◆ Up to four LACP or static 4-port trunks
◆ RADIUS and TACACS+ authentication
◆ Rate limiting for bandwidth management
◆ CoS support for four-level priority
◆ Full support for VLANs with GVRP
◆ IP Multicasting with IGMP Snooping
Management Guide
SMC6224M
