9
1-5. Installing new Ink cartridge(s)
1) Remove new ink cartridge from
sealed pouch.
(Hold cartridge by round plastic
tab to avoid contamination)
2) Remove Mylar from face of new
cartridge.
CAUTION
Do not touch ink cartridge’s metallic
connector surface with your fingers.
Doing so will contaminate the
connector and produce bad print
quality.
3) Turn the printer on and open
the front cover of printer.
4) Pull down cartridge holder.
10
5) Take out old ink
cartridge(s).
Place new cartridge(s)
into carriage.
Hold plastic tab to ensure
clean installation.
Black cartridge goes into
the left carriage.
The color cartridge goes
into right carriage.
(tab faces front of
printer.)
6) Close cartridge holder.
7) Close front cover of
printer.
Notice
The ink drop counter is automatically reset when the ink-cartridge is installed.
