Samsung SRP-500 - Manual (Page 32)

55
ESC c 5 n
[Name] Enable/disable panel buttons
[Format] ASCII ESC c 5 n
Hex 1B 63 35 n
Decimal 27 99 53 n
[Range] 0 ≤ n ≤ 255
[Description] Enables or disables the panel buttons.
• When the LSB of n is 0, the panel buttons are enabled.
• When the LSB of n is 1, the panel buttons are disabled.
[Notes]
• Only the least significant bit of "n" is valid.
• When the panel buttons are disabled, no buttons on the panel are usable.
• If "disabled" is set, the paper feed switch no longer functions.
[Default] n = 0
ESC d n
[Name] Print and feed n lines
[Format] ASCII ESC d n
Hex 1B 64 n
Decimal 27 100 n
[Range] 0 ≤ n ≤ 255
[Description] Prints the data in the print buffer and feeds n lines.
[Notes]
• This command sets the print starting position to the beginning of the line.
• The amount of paper fed per line is based on the value set using the line
spacing command (ESC 2 or ESC 3)
[Reference]
56
ESC g<0> [ ]k[d1…dm]k
[Name] Start macro record
[Format] ASCII ESC g <0> [ ]k[d1…dm]k
Hex 1B 67 00 [ ]k[d1…dm]k
Decimal 27 103 00 [ ]k[d1…dm]k
[Range]
k ≤ 10
0 ≤ nL ≤ 255
0 ≤ nH ≤ 255
[(256×nH) + nL ]
1
+ …..+ [(256×nH) + nL ]
k
< 2Mbit
0 ≤ d ≤ 255
[Description] Start macro definition (Define logo)
• k = the number of total macro index
• (256×nH) + nL = the Length of each macro
• m = (256×nH) + nL.
[Notes] The SRP-500 Printer maintains a 2M bit (256KB) section
of flash memory to save user information
• This function is useful define NV bit image (Logo).
[Reference] User easily download Logo to printer using SRP-500
StoreMaker Utility.
ESC g n
[Name] Execute Macro
[Format] ASCII ESC g n
Hex 1B 67 n
Decimal 27 103 n
[Range] 1 ≤ n ≤10
[Description] Execute macro using the parameter by n.
[Notes]
• n = Macro index number.
