Samsung SRP-500 User Manual
Page 33
57
ESC m
[Name]
Execute partial cut
[Format]
ASCII
ESC
m
Hex
1B
6D
Decimal 27
109
[Description]
Execute partial cut with one point uncut
ESC p m t1 t2
[Name]
Generate pulse
[Format]
ASCII
ESC
p
m t1 t2
Hex
1B
70
m t1 t2
Decimal 27
112 m t1 t2
[Range]
m = 0, 1, 48, 49
0 ≤ t1 ≤ 255
0 ≤ t2 ≤ 255
[Description]
Outputs the pulse specified by t1 and t2 to connector pin
m as follows:
n Connector
Pin
0
Drawer kick-out connector pin 2
1
Drawer kick-out connector pin 5
[Notes]
• The pulse ON time is [ t1 x 2] ms and the OFF time is [ t2 x 2] ms.
• When t2 < t1, the printer processes t1 x 2 ms.
[Reference]
58
ESC r n
[Name]
Select print color
[Format]
ASCII
ESC
r
n
Hex
1B
72
n
Decimal 27
114
n
[Range]
n = 0, 1, 48, 49
[Description]
Selects the print color.
n Selected
color
0, 48
Black
1, 49
Red
[Notes]
• Valid only when input at the beginning of a line.
[Default]
n = 0
ESC t n
[Name]
Select character code table
[Format]
ASCII
ESC
t
n
Hex
1B
74
n
Decimal 27
116 n
[Range]
n = 0, 2, 3, 4, 5, 16, 17, 18, 19, 21, 22, 23
[Description]
Selects a page n from the character code table.
n Page
0 PC437
2 PC850
3 PC860
4 PC863
5 PC865
16 PC1252
17 PC866
18 PC852
19 PC858
21 PC862
22 PC864
23 PC874
[Default]
n = 0
[Reference]
