Samsung SRP-500 - Manual (Page 27)

45
ESC - n
[Name] Turn underline mode on/off
[Format] ASCII ESC – n
Hex 1B 2D n
Decimal 27 45 n
[Range] n = 0, 1, 48, 49
[Description] Turns underline mode on or off,
• When n = 0 or 48, underline mode is turned off.
• When n = 1 or 49, underline mode is turned on.
[Notes]
• Underlines can be printed for all characters, but not for the space set by
HT.
• This command and ESC ! turn underline mode on or off in the same way.
• If n is out of the specified range, this command is ignored.
[Default]
n = 0
[Reference] ESC !
ESC 2
[Name] Select default line spacing
[Format] ASCII ESC 2
Hex 1B 32
Decimal 27 50
[Description] Selects default (1/6-inch) line spacing.
[Reference] ESC 3
46
ESC 3 n
[Name] Set line spacing
[Format] ASCII ESC 3 n
Hex 1B 33 n
Decimal 27 51 n
[Range] 0 ≤ d ≤ 255
[Description] Sets the line spacing to [ n x (1/192)] inches.
[Default] n = 32 (1/6 inch)
[Reference] ESC 2
ESC <
[Name] Return home
[Format] ASCII ESC <
Hex 1B 3C
Decimal 27 60
[Description] Moves the print head to the standby position.
[Notes]
• The leftmost end is detected by the home position sensor.
• Since the home position is detected when this command is executed, the
printing position may shift after this command is executed.
ESC = n
[Name] Select device
[Format] ASCII ESC = n
Hex 1B 3D n
Decimal 27 61 n
[Range] n = 1
[Description] Selects device to which host computer sends data.
• n = 1 ; enable
• n = 2 ; disable
[Default]
n = 1
