E pump exploded view parts list (cont.), Pressure w asher – Shark HPB-3520 User Manual
Page 51
97-6068, 97-6131 • REV. 3/06
51
PRESSURE
W
ASHER
OPERA
T
OR’S MANU
AL
ITEM
PART NO.
DESCRIPTION
QTY
35
70-140002
Washer
4
36
70-180126
Flange Screw
4
37
70-000104
Crankshaft Seal
1
38*
70-030211
Plunger Nut
3
39*
70-120023
Plunger 15mm (2020F,
2825F, 3525F)
3
70-120022
Plunger 18mm
(2020S, 2825S)
3
40*
70-140027
Copper Spacer
3
41*
70-160130
O-Ring Ø1.78 x 5.28
3
42*
70-000913
Teflon Ring
3
43
70-000320
Plunger Rod
3
44
70-1502.04
Connecting Rod Pin
3
45
70-010008
Connecting Rod
3
46
70-140102
Spring Washer
6
47
70-180132
Connecting Rod Screw
6
48
70-060104
O-Ring Ø2.62 x 107.62
1
49
70-020352
Crankcase Cover
1
50
70-060302
Gasket
1
51
70-070005
Sight Glass
1
E PUMP EXPLODED VIEW PARTS LIST (CONT.)
REPAIR KIT
NUMBER
70-261408
70-261410
70-261409
70-261411
70-261404
70-261405
70-260028 70-260826
KIT
DESCRIPTION
Plunger Seal
15mm
2020F
2825F
3525F
Plunger
Seal 18mm
2020S
2825S
Complete Seal
Packing 15mm
2020F
2825F
3525F
Complete
Seal Packing
18 mm
2020S
2825S
Plunger
15mm
2020F
2825F
3525F
Plunger
18mm
2020S
2825S
Complete
Valve
Plunger
Oil Seals
ITEM NUMBERS
INCLUDED
3, 5, 6
3, 5, 6
2, 3, 4, 5,
6, 7
3, 4, 5, 6, 7, 8
38, 39, 40,
41, 42
38, 39, 40,
41, 42
11, 12, 13
2
NUMBER OF
CYLINDERS KIT
WILL SERVICE
3
3
1
1
1
1
6
3
