Pressure w asher – Shark HPB-3520 User Manual
Page 25
97-6068, 97-6131 • REV. 3/06
25
PRESSURE
W
ASHER
OPERA
T
OR’S MANU
AL
2015, 3520 PARTS LIST
ITEM
PART NO.
DESCRIPTION
QTY
1
10-020110
Label, Use Only Kerosene
1
2
10-02025A
Label, "Hot/Caliente"
with Arrows Warning
1
3
10-08018
Label, Warn, Service Cord
1
4
10-09004
Label, Hot Water Outlet
1
5
11-013
Label, Logo Large (HPB)
1
11-016
Label, (HCV)
1
6
11-0101
Label, Warning (Lexan)
1
7
Please See Specifications Pages
8
Please See Specifications Pages
9
Please See Specifications Pages
10
2-1019
Elbow, 3/8” Female
1
11
95-07102242
Frame, Junior
1
12
2-10942
Swivel, 1/2" MP x 3/4" GHF
w/Strainer
1
13
7-014832
Tank Head Insul.
1
14
90-40001
Washer, 1/4"
4
15
6-0128
Conduit, 25"
1
16
6-051591
Connector 1/2" L/T 90° Black 1
17
2-00742
Adapter, 1/2” x 1/2” Pipe
1
18
4-011184
Downstream Injector Assy,
Non-Adj #3 (3520)
1
4-011183
Downstream Injector Assy,
Non-Adj #2 (2015)
1
19
95-07121218
Coil, Heating, Jr.
1
20
90-1016
Bolt, 3/8" x 1"
4
21
2-01041
Pad, Soft Rubber, 50 Duro
2
22
2-01103
Grip, 1" SQR, Handle
2
23
2-011506
Tank Fuel, 9 Gallon Poly,
Black
1
24
2-01167
Cap, Fuel Tank Plastic
H60-AV
1
25
4-0303
Wheel & Tire, 4" Steel Rim
w/Tube
2
26
4-05088
Adjustable Thermostat
1
27
90-1006
Bolt, 5/16" x 3/4"
4
28
6-01059
GFCI, 240V 1PH 30A w/36' 10-3
Cord (3520)
1
6-01060
GFCI, 120V/20A w/36’ Cord
(2015)
1
29
2-300812
Pump Protector, 1/4"
1
30
10-09003
Label, Cold Water Inlet HS
1
31
2-1089
Hose Barb, 1/4" Barb x 1/4"
Pipe, 90°
1
32
2-00602
Elbow, 1/2" JIC x 1/2" FM
1
33
6-021720
Pressure Switch, 1/4"
1
34
2-0031
Elbow, 3/8" Street
1
ITEM
PART NO.
DESCRIPTION
QTY
35
2-0053
Elbow, 1/2” JIC, 3/8”,90°
1
36
2-2007
Coupler Plug, 3/8" Male
1
37
90-50045
Clip, Retainer
4
38
90-2002
Nut, 3/8" ESNA
2
39
90-4002
Washer, 3/8" Flat
6
40
90-4015
Washer, 3/8" x 2-1/2"
2
41
90-10201
Bolt, 3/8" x 2-1/4"
2
42
2-3409
Disk, Rupture Assy, 7000 PSI 1
43
2-1108
Hose Barb, 1/2" Barb x 3/8"
MPT, Push-On
1
44
4-02110000
Hose, 1/2", Push-On
2.5 ft.
45
95-07290029
Tank Head Assy. 16" x 8"
1
46
95-07101226
Block, 1/2" x 1/2", Discharge 1
47
95-07102205
Axle, 5/8" x 25.710"
1
48
90-20041
Collar, 5/8"
2
49
90-20040
Nut, 3/8" Flange, Whiz Loc
4
50
4-02047729
Hose, 3/8" x 29"
1
51
Please See Specifications Pages
52
95-07290053
Retainer, Burner Insulation
1
53
7-01482
Insulation, Tank Bottom,
1" Blanket
1
54
90-40125
Washer, 3/8" x 1"
2
55
90-4001
Washer, 5/16", Flat
8
56
90-2001
Nut, 5/16", ESNA
4
57
90-2020
Nut, Cage, 3/8" x 12 GA
4
58
95-07200129
Wrap, Outer Coil,
Red (3520)
1
95-07290013S
Wrap, Outer Coil, SS (2015)
1
59
95-07290007
Tab, Outer Wrap
4
60
2-00091
Nipple, 1/2" x 3", Galv.
1
61
90-19711
Screw, 1/4" x 1/2", Whiz Loc 12
62
90-19960
Screw, 3/8" x 1-1/4" Whiz Loc 4
63
90-19980
Screw, 1/4" x 1"
4
64
90-200012
Nut, 1/4" Flange
4
65
2-0155
Fastener, Ratchet, Black
Nylon
2
66
90-4005
Washer, 5/8" Flat
2
67
2-00101
Nipple, 1/2" x 4", Galv.
1
68
2-9040
Clamp,Hose UNI .46-.54
6
69
6-051595
▲ Refief, Strain, LQ Tite(3520)1
6-051532
▲ Strain Relief w/Gasket
(2015)
1
70
6-05181B
▲ Lock-Nut, 3/4"
1
71
6-0108
▲ Cord, Service, 10/3(3520) 44"
6-01041
▲ Cord, Service, 12/3(2015) 44"
