3530, 4020 FLOAT TANK OPTION PARTS LIST
ITEM
PART NO.
DESCRIPTION
QTY
1
2-011641
Tank, Float
1
2
95-071022137
Shelf, Float Tank
1
3
90-1996
Screw, 3/8" x 3/4" HH NC,
Whiz Loc
4
4
2-0053
Elbow, 1/2" JIC x 3/8" Fem,
90°
1
5
90-19712
Screw, 5/16" x 1/2" Whiz Lock 4
6
4-02110000
Hose, 1/2", Push-On
20 in
7
2-9002
Clamp, Screw, #6
3
8
2-30122
▲ Valve, Float
1
2-01021
▲ Ball Float
1
9
2-10861
Hose Barb, 5/8" Barb x 1/2" ML
Pipe
1
10
2-1020
Elbow, 1/2" Female, Brass
1
11
2-10067
Modified Close Nipple, 1/2"
NPT, 5/16"
1
12
2-00602
Elbow, 1/2" x 1/2" Fem, 90°
1
13
4-02047722
Hose, 3/8" x 22", 2 Wire,
Pressure Loop
1
14
2-10942
Swivel, 1/2" MP x 3/4" GHF
w/Strainer
1
15
95-07162007
Hose Connection Bracket
1
16
90-1001
Bolt, 1/4" x 3/4", NC HH
2
17
90-20040
Nut, 3/8", Flange, Whiz Loc,
NC
4
18
2-1003
Nipple, 1/4" Hex
1
19
2-3015
Valve, Flow Control
1
20
2-1085
Hose Barb, 1/4" Barb x 1/4" ML
Pipe
1
21
2-9040
Clamp, Hose, UNI, .46-.54
1
(Float Tank w/Steam)
3
22
4-02080000
Tube, 1/4" x 1/2", Clear
Vinyl
6 ft.
23
2-1905
Strainer, 1/4" Brass
w/Check Valve
1
24
2-011642
Cover, Float Tank, Portotenica 1
25
2-1062
Elbow, 1/2" JIC x 1/2", 90°
1
26
2-1105
Swivel, 1/2" JIC Fem,
Push-On
1
27
4-02110003
Hose, 5/8" Push-On
12 in
28
90-2000
Nut, 1/4", ESNA, NC
2
29
90-4000
Washer, 1/4" Flat, SAE
4
ITEM
PART NO.
DESCRIPTION
QTY
30
2-1089
Hose Barb, 1/4" Barb x 1/4"
Pipe, 90°
2
31
2-30151
Valve, Flow Control
w/Metering
1
32
2-0004
Nipple, 1/4" Hex Steel
1
33
70-460146
Cap, Valve
with 1/4" Gauge Port
1
34
4-02100000
Hose, 1/4", Push-on
14 in
35
6-021730
Flow Switch
1
36
2-00270
Elbow, 3/8" Male Pipe
1
37
2-10352
Cross, 1/2" Female w/1/8 Hole1
38
10-99011
Label, Open For Steam
1
39
2-11031
Adapter, 1/4"x 1/8"
1
40
90-199400
Screw, 10/32" x 2-1/2"
1
41
90-017
Nut, 10/32” Keps
1
42
2-1040
Tee, 1/4” Street
1
43
2-1007
Nipple, 1/2" Hex
1
44
2-1035
Cross, 1/2" Female
1
45
2-1076
Bushing, 1/2" x 1/4"
1
46
2-1053
Nipple, 1/2" JIC x 1/2" Pipe
1
47
2-1105
Swivel, 1/2" JIC Female
Push-on
2
48
4-02110000
Hose, 1/2" Push-on
16"
49
2-1060
Elbow, 1/2 JIC x 3/8" 90°
1
50
5-3027
Unloader VB8 w/Switch
1
51
6-021720
Switch, Pressure 1/4 Port
1
52
2-0031
Elbow, 3/8" Street
1
53
2-0074
Adapter, 3/8" x 3/8" Street
1
54
2-1084
Hose Barb,
1/4 Barb x 1/8" Pipe
1
▲ Not Shown
