Pressure w asher – Shark HPB-3520 User Manual
Page 34
97-6068, 97-6131 • REV. 3/06
OPERA
T
OR’S MANU
AL
PRESSURE W
ASHER
34
ITEM
PART NO.
DESCRIPTION
QTY
10
4-12804000
Nozzle, SAQCMEG 0004
Red (3530)
1
4-12804015
Nozzle SAQCMEG 1504
Yellow (3530)
1
4-12804025
Nozzle, SAQCMEG 2504
Green (3530)
1
4-12804040
Nozzle, SAQCMEG 4004
White (3530)
1
11
2-0103
Grommet, Rubber,
Nozzle Holder
4
12
95-07102240
Cover, Elec Box
1
13
90-1991
Screw, 10/32" x 1/2"
13
(Time Delay Option)
2
14
10-08021
Label, Disconnect Power
Supply
1
15
90-2018
Nut, Cage, 10/32" x 16 ga.
6
16
90-1994
Screw, 10/32" x 1-1/4"
1
(Auto Start/Stop Option)
1
17
90-017
Nut, 10/32" Keps
12
(Time Delay Option)
2
(Auto Stop/Start Options)
1
18
11-0304
Label, Control Panel (HPB)
1
11-3028
Label, Control Panel (HCV)
1
3530, 4020 CONTROL PANEL PARTS LIST
ITEM
PART NO.
DESCRIPTION
QTY
19
11-1042
Label, Ground
1
20
6-051591
Connector, 1/2", L/T 90°, Blk
1
21
6-05152
Strain Relief, STRT, L/T, Sm
1
22
6-05181B
Locknut, 3/4" (4020)
2
(3530)
1
6-05172
Locknut, 3/4” Conduit (3530)
1
23
6-05181A
Locknut, 1/2"
1
24
2-01403
Bushing, Snap 5/8"
1
25
6-051595
Strain Relief, STRT, L/T, LG
1
26
9.800-049.0
Label, Cleaning Solution
1
27
9.800-018.0
Label, Tipover Hazard
1
28
6-0504
Block, Terminal, 4 Pole (Time
Delay Option, Auto Start/Stop
Option)
1
29
6-036880
Timer, Solid State, 120V, 5-60
Mins Adj. (Auto Start/Stop
Option)
1
30
90-16
Screw, 8/32” x 3/4” (Time
Delay Option, Auto Start/Stop
Option)
2
31
90-200490
Nut, 8/32” Keps (Time Delay
Option, Auto Start/Stop
Option)
2
32
6-021595
Rail, Din (Time Delay Option) 2”
33
6-03700
Timer, Multi-Function (Time
Delay Option)
1
34
6-03541
Base, Relay (Time Delay
Option)
1
35
6-03621
Relay, 120V (Time Delay
Option)
1
▲ Not Shown
