97-6068, 97-6131 • REV. 3/06
OPERA
T
OR’S MANU
AL
PRESSURE W
ASHER
28
ITEM
PART NO.
DESCRIPTION
QTY
1
10-020110
Label, Use Only Kerosene
1
2
10-02025A
Label, "Hot/Caliente" with
Arrows Warning
1
3
10-08018
Label, Warning, Service Cord 1
4
10-09004
Label, Hot Water Outlet
1
5
11-013
Label, Logo, Large (HPB)
1
11-016
Label, Logo, Large (HCV)
1
6
11-0101
Label, Warning (Lexan)
1
7
2-01041
Pad, Soft Rubber, 50 Duro
2
8
2-01103
Grip, 1" SQR, Handle
2
9
2-011506
Tank, Fuel, 9 Gallon Poly,
Black
1
10
2-01167
Cap, Fuel Tank, Plastic
H60-AV
1
11
2-30082
Pump Protector, 1/2" PTP
1
12
95-07102241
Frame
1
13
4-011184
Downstream Injector Assy.,
Non Adj. #3
1
14
95-07102243
Power Platform (4020)
1
95-07102245
Power Platform, Large (3530) 1
15
2-0155
Fastener, Ratchet Blk Nylon
2
16
4-0307
Wheel & Tire, 6" Steel Rim
2
17
4-05088
Thermostat, General 302°
1
18
Please See Specifications Pages
19
Please See Specifications Pages
20
Please See Specifications Pages
21
2-00742
Adapter, 1/2” x 1/2”
1
22
90-2020
Nut, Cage, 3/8" x 12 Gauge
4
23
7-014865
Insulation Blanket,
18" OD x 4.5" ID
1
24
2-1019
Elbow, 3/8" Female
1
25
90-200012
Nut, 1/4", Flange
4
26
90-1016
Bolt, 3/8" x 1" (3530)
6
(4020)
8
27
90-10220
Bolt, 3/8" x 3-1/2", TAP
2
28
95-07164054
Coil 18"
1
7-01433
▲ Insulation Blanket
1
29
6-021720
Pressure Switch, 1/4"
1
30
90-40001
Washer, 1/4"
7
31
95-07164053
Outer Wrap, 18" Coil (HPB)
1
95-071640521
Outer Wrap, SS (HCV)
1
32
95-07163088
Wrap, Burner, Top
18”
33
7-014866
Insulation Disk
1
34
2-0031
Elbow, 3/8" Street
1
35
2-2007
Nipple, 3/8"
1
36
95-07101226
Discharge Block, 1/2" x 1/2"
1
37
2-00602
Elbow, 1/2" JIC x 1/2" FEM
1
ITEM
PART NO.
DESCRIPTION
QTY
38
4-02047722
Hose, 3/8" x 22"
1
39
2-0053
Elbow, 1/2" JIC x 3/8", 90°
1
40
90-10201
Bolt, 3/8" x 2-1/4"
1
41
90-2007
Nut, 3/8" Hex
2
42
2-3409
Rupture Disk Assy, 7000 PSI 1
43
2-1108
Hose Barb, 1/2" Barb x 3/8"
MPT, Push-On
1
44
4-02110000
Hose, 1/2" Push-On
2.5 ft.
45
70-460146
Cap, Valve w/1/4" Port
1
46
90-20040
Nut, 3/8" Flange, Whiz Loc
4
47
2-10942
Swivel, 1/2", GHF
1
48
90-4005
Washer, 5/8" Flat
2
49
90-19980
Screw, 1/4" x 1"
7
50
2-011724
Belt Guard
1
51
90-20041
Collar, 5/8"
2
52
95-07102215
Axle, SR
1
53
95-07102244
Pump Rail
1
54
Please See Specifications Pages
55
Please See Specifications Pages
56
Please See Specifications Pages
57
Please See Specifications Pages
58
Please See Specifications Pages
59
Please See Specifications Pages
60
90-50045
Clip, Retainer
4
61
11-3229
Label, Belt Guard (HPB)
1
11-32289
Label, Belt Guard (HCV)
1
62
95-07290053
Retainer, Burner Insulation
1
63
90-19960
Screw, 3/8" x 1-1/4" Whiz
Loc
4
64
2-00091
Nipple, 1/2" x 3", Galv.
1
65
2-00101
Nipple, 1/2" x 4", Galv.
1
66
95-07290007
Tab, Outer Wrap
4
67
90-20231
Nut, Cage, 1/4" x 12 GA
14
68
90-19711
Screw, 1/4" x 1/2", Whiz
Loc
15
69
90-19708
Screw, 1/4" x 1-1/4", Whiz
Loc
4
70
90-40125
Washer, 3/8" x 1"
2
71
90-4002
Washer, 3/8", Flat (3530)
23
(4020)
25
72
6-01059
GFCI, 230V, 30 Amp (4020)
1
6-010690
GFCI, 240V, 40 Amp (3530)
1
73
90-4015
Washer, 7/16" x 2-1/2"
2
74
2-1085
Hose Barb, 1/4"
2
75
90-2002
Nut, 3/8", ESNA
13
76
4-02100000
Fuel Line, 1/4"
28”
3530, 4020 PARTS LIST
