Shark HPB-3520 - Manual (Page 22)

97-6068, 97-6131 • REV. 3/06
OPERA
T
OR’S MANU
AL
PRESSURE W
ASHER
22
ITEM PART NO. DESCRIPTION QTY
1 10-02025A Label, Hot/Caliente w/Arrows
Warning
1
2 95-07290029 Tank Head Assy 1
3 7-014832 Insulation, Top Head 1
4 90-50045 Clip, Retaining U-Type 4
5 2-0115090 Tank, Fuel 6 Gal Blank 1
6 4-02100000 Hose, 1/4", Push-On 12"
7 11-013 Label, Logo, Large 1
8 90-19710 Screw, 1/4" x 3/4" HH NC,
Whiz Loc
4
9 7-01482 Insulation, Bottom 1
10 95-07102253 Coil Wrap 1
11 4-02110000 Hose, 1/2" Push-On 30"
12 2-0008 Nipple, 1/2" Hex Steel 1
13 7-01487 Insulation, Blanket 1
14 2-1019 Elbow, 3/8" Female 1
15 10-09004 Label, Hot Water Outlet 1
16 2-3409 Disk, Rupture Assy, 7000
PSI
1
17 2-1108 Hose Barb, 1/2" Barb x 3/8"
MPT, Push-On
1
18 2-1085 Hose Barb, 1/4" Barb x 1/4" ML
Pipe
2
19 2-9040 Clamp, Hose, UNI .46-.54 7
20 2-2007 Nipple, 3/8" x 3/8" NPT ST
Male
1
21 90-2020 Nut, 3/8” x 12 Gauge 4
22 2-99031 Filter, Diesel, Disposable 1
23 90-2022 Nut, Cage, 1/4" x 16 Gauge 4
24 95-07102247 Fuel Strap, Long 2
25 90-1996 Screw, 3/8" x 3/4" HH NC,
Whiz Loc
2
26 10-020110 Label, Use Only Kerosene 1
27 2-011576 Cap, Non-Vented, Plastic 1
28 11-1043 Label, Warning, Pictorial 1
29 2-01041 Pad, Soft Rubber, 50 DURO 2
30 95-07102248 Fuel Strap, Short 2
31 2-30057 Valve, 1/4" Shut-Off 1
32 2-010061 Bushing, Rubber, Nitrile 3
33 2-00601 Elbow, 1/2" JIC, 3/8" Fem,
90°
1
34 4-02047732 Hose, 3/8" x 32", 2 Wire,
Pressure Loop
1
35 6-01041 Cord, Service, SEO, 12/3,
Coleman
33"
36 10-99078 Label, Motor Overload Reset,
Lexan
1
ITEM PART NO. DESCRIPTION QTY
37 Please See Specifications Pages
38 2-30082 Pump Protector, 1/2" PTP 1
39 6-021720 Switch, Pressure N/O, 1/4" NPT
SS
1
40 Please See Specifications Pages
41 2-00601 Elbow, 1/2" JIC x 3/8" Fem 1
42 2-10942 Swivel, 1/2" MP x 3/4" GHF,
w/Strainer
1
43 2-1046 Plug, 1/4" Countersunk 1
44 Please See Specifications Pages
45 90-1016 Bolt, 3/8" x 1", NC HH 4
46 2-10866 Hose Barb, 1/4" x 3/8" Double 1
47 90-1006 Bolt, 5/16" x 3/4" NC GR 5 CS
ZN
8
48 90-4001 Washer, 5/16", Flat, SAE 12
49 10-09003 Label, Cold Water Inlet, HS 1
50 2-0155 Fastener, Ratchet, Black
Nylon
2
51 2-01103 Grip, 1" Sqr, Handle 2
52 2-00742 Adapter, 1/2" x 1/2" Pipe 1
53 95-07102218 Assy, Frame 1
54 90-40125 Washer, 3/8" x 1" 2
55 90-20012 Nut, Whiz Loc 5/16 4
56 4-02100000 Hose, 1/4" Push-On 21"
57 95-07102311 Axle, 5/8" x 22" 1
58 Please See Specifications Pages
59 90-4015 Washer, 7/16" x 2-1/2", Zinc,
PG Foot
2
60 90-4005 Washer, 5/8", Flat, SAE 2
61 6-01060 GFCI, 120V 20A, w/36' 12-3
Cord
1
62 10-08018 Label, Warning, Service Cord 1
63 4-02100000 Hose, 1/4” Push-On 6”
64 6-0516 Relief, Strain, 1/2” Metal 1
65 90-4002 Washer, 3/8", SAE, Flat 10
66 90-10201 Bolt, 3/8" x 2-1/4", HH,
Grade .5
2
67 90-20040 Nut, 3/8", Flange Whiz Loc,
NC
6
68 15-070042532 Cap, Valve, with 1/4" Gauge
Port
1
69 90-19960 Screw, 3/8” x 1-1/4” 4
70 95-07290053 Retainer, Burner Insulation 1
71 4-0303 Wheel & Tire Assy, 4" Steel Rim
w/Tube
2
72 90-20041 Collar, 5/8" Bore Shaft 2
EXPLODED VIEW - 2011 PARTS LIST
