97-6068, 97-6131 • REV. 3/06
37
PRESSURE
W
ASHER
OPERA
T
OR’S MANU
AL
O PEN FO R
ST EA M
10 -99 011
O PE N FO R ST EA M
10 -99 01 1
2015, 3520 SERIES ITEM PART NO. DESCRIPTION QTY
1 2-1089 Hose Barb, 1/4" Barb x 1/4"
Pipe, 90°
2
2 2-9040 Clamp, Hose, UNI .46-.54 2
3 2-30151 Valve, Flow Control
w/Metering
1
4 2-0004 Nipple, 1/4" Hex Steel 1
5 70-460148 Cap, Valve with 1/4" Gauge
Port
1
6 6-021730 Switch, Flow, MV-60 1
7 2-10942 Swivel, 1/2" MP x 3/4" GHF
w/Strainer
1
8 Unloader , Please See Specifications Pages
9 Pump , Please See Specifications Pages
10 10-99011 Label, Open For Steam 1
11 4-02100000 Hose, 1/4" Push-On 14"
12 2-0053 Elbow, 1/2" JIC x 3/8" 1
13 2-00270 Elbow, 3/8" Male Pipe 1
14 2-30082 Pump Protector, 1/2” 1
ITEM PART NO. DESCRIPTION QTY
1 2-1089 Hose Barb, 1/4" Barb x 1/4"
Pipe, 90°
1
2 2-9040 Clamp, Hose, UNI .46-.54 2
3 2-30151 Valve, Flow Control
w/Metering
1
4 2-0004 Nipple, 1/4" Hex Steel 1
5 70-460146 Cap, Valve with 1/4" Ga. Port 1
6 6-021730 Switch, Flow, MV-60 1
7 2-10942 Swivel, 1/2" MP x 3/4" GHF
w/Strainer
1
8 Unloader , Please See Specifications Pages
9 Pump , Please See Specifications Pages
10 10-99011 Label, Open For Steam 1
11 4-02100000 Hose, 1/4" Push-On 14"
12 2-0053 Elbow, 1/2" JIC x 3/8" 1
13 2-00270 Elbow, 3/8" Male Pipe 1
14 2-1088 Hose Barb, 1/4” Barb x 1/8”
Pipe
1
3530, 4020 SERIES
6
12
8
5
10
2
1
2
11
1
7
9
4
3
6
8
5
10
2
14
2
11
1
7
9
4
3
13
12
13
STEAM OPTIONS & PARTS LISTS
14
