97-6068, 97-6131 • REV. 3/06
OPERA
T
OR’S MANU
AL
PRESSURE W
ASHER
44
SPECIFICATIONS
PARTS SPECIFICATIONS:
PUMP MOTOR
Machine Pump Pump Pulley Bushing Motor Motor
Part # Unloader Part # Unloader Pulley Part # Bushing Part # Size Voltage Part # Pulley
2011(HPB)WMH-2521F 5-1618 5-3150 NA NA NA NA 1.5 HP 120v/1ph/60Hz 5-1046 NA
2015(HCV) HE2020F 5-1201 5-3329 NA NA NA NA 2 HP 120v/1ph/60Hz 5-1047 NA
3520(HPB) SE3525F 5-1405 5-3329 NA NA NA NA 5 HP 230v/1ph/60Hz 5-1053 NA
4020(HPB) SM-4035 5-1420 5-3029 2AK74H 5-40207401 24 MM 5-512024 6 HP 230v/1ph/60Hz 5-10401 2AK54H
4020(HCV) HM-4035 5-1220 5-3029 2AK74H 5-40207401 24 MM 5-512024 6 HP 230v/1ph/60Hz 5-10401 2AK54H
3530(HPB) SM-4035 5-1420 5-3029 2BK80H 5-40508001 24 MM 5-512024 7.5 HP 230v/1ph/60Hz 5-1013 2BK52H
3530(HCV) HM-4035 5-1220 5-3029 2BK80H 5-40508001 24 MM 5-512024 7.5 HP 230v/1ph/60Hz 5-1013 2BK52H
