7 Appendix
Users Manual SX
TCP/IP Setup
Tab Explanation
Factory
Default
Enable/Disable TCP/IP protocol operations. This
has influence on the configuration of Setup Tools,
LPR, FTP, TELNET, SNMP, HTTP and other
protocols over TCP/IP.
ENABLE
Enable/Disable DHCP/BOOTP protocol operations.
DHCP/BOOTP is a protocol, via which IP address
gets assigned by the BOOTP server or DHCP
server. If you use DHCP/BOOTP server, the
DHCP/BOOTP server must be in the same
segment as the print server. This print server
detects DHCP and BOOTP automatically. If more
than 1 address is returned, the IP address which is
returned first will be used.
ENABLE
Enable/Disable RARP protocol operations. RARP
is a protocol, via which the IP address gets
assigned by the RARP server. If you use a RARP
server, the RARP server must be in the same
segment as the print server.
ENABLE
Setting the Print Server IP address. The IP address
must be 4 numbers, each between 0-255 (eg.
192.168.100.10).
0.0.0.0
Setting the print server subnet mask. The subnet
mask must be 4 numbers, each between 0-255
(eg. 255.255.255.0). However, entering 0.0.0.0
would not be valid, and the subnet mask
corresponding to the IP address would be used
automatically.
0.0.0.0
Setting the default gateway address. The default
gateway address must be 4 numbers, each
between 0-255 (eg. 192.168.100.240). If you use a
gateway, the gateway must be in the same
segment as the print server.
0.0.0.0
You can select to use a banner page when printing
with LPR and FTP. (A banner page is print cover
page with print job explanations.)
DISABLE
Use FTP/LPD Banner
Item
Use TCP/IP Protocol
Use DHCP/BOOTP
Use RARP
Subnet Mask
T
C
P/IP
IP Address
Default Gateway
