QUICKIE GTX PAGE 71
TUBULAR SIDE LATCH FOOTREST ASSM
Pos. Item Number Description Remarks
2 240103 RIVET POP AD54ABS-154
3 560040 PLATE FOOT HANGER 10W
3 560041 PLATE FOOT HANGER 11W
3 560043 PLATE FOOT HANGER 13W
3 560045 PLATE FOOT HANGER 15W
3 560047 PLATE FOOT HANGER 17W
4 230132 SHCS M4 X .7 X 10
5 050129-002 LOCKWASHER HIGH COLLAR M4
6 052289 BUTTON LEVER LATCH
7 100837 SPRING COMP .25OD X 1.0LG
8 052103 LATCH PLUNGER FOOTREST
9 100842 ASSY LATCH PIVOT FOOTREST
10A 052020-001 TUBE FOOTREST STD
10B 052020-002 TUBE FOOTREST LNG
11 230010 SHCS M6X 1 X 16 BLK
Pos. Item Number Description Remarks
12 050129-001 LOCKWASHER HIGH COLLAR M6
13 052022 CLEVIS PIVOT TUBE
14 052282 PIN PIVOT FOOTREST
15 262133 WASHER LOCK M6
16 013147 BHCS M6X1X12MM BLK
1-8 100830-010 ASSY TUBE FRST TBLR W-CVR 12W
1-8 100830-011 ASSY TUBE FRST TBLR W-CVR 13W
1-8 100830-012 ASSY TUBE FRST TBLR W-CVR 14W
1-8 100830-013 ASSY TUBE FRST TBLR W-CVR 15W
1-8 100830-014 ASSY TUBE FRST TBLR W-CVR 16W
1-8 100830-015 ASSY TUBE FRST TBLR W-CVR 17W
1-8 100830-016 ASSY TUBE FRST TBLR W-CVR 18W
1-8 100830-017 ASSY TUBE FRST TBLR W-CVR 19W
1-8 100830-018 ASSY TUBE FRST TBLR W-CVR 20W
1,4-8 100830-001 ASSY TUBE FTRST TUBULAR 12W
