QUICKIE GTX PAGE 25
WHEEL LOCK (PUSH-TO-LOCK)
Pos. Item Number Description Remarks
1 560500-QU HB PLASTIC COVER
3 560126 .250 ID .312 OD BUSHING PLST
4 226110 1/4-28 x 1 BH C/S
5 550447 WHEEL LOCK SLIDE BLOCK LONG BLK
6 201100-QU 1/4-28 NYLOCK NUT THIN
7 561028 1/4" NYLON WASHER
8 230021 BHCS M5 X.8 X 20MM TORX T-25
9 050129-001 LOCKWASHER HIGH COLLAR M6
10B 050160 CLAMP WHL LCK LNG MALE
10A 050120 CLAMP WHL LCK MALE
11B 050161 CLAMP WHL LCK LNG FEMALE
11A 050121 CLAMP WHL LCK FEMALE
12 880904 GRADE AID PLATE W/WHL R BLK
12 880905 GRADE AID PLATE W/WHL L BLK
13 483027 1/4 X 1/4 ALUM SPACER BLK
1,2 881748 WHEEL LOCK ASSM R PUSH
1,2 881749 WHEEL LOCK ASSM L PUSH
8-10A,11A 050229 WHEEL LOCK CLAMP ASSM BLK
8,9,10B,11B 050230 WHEEL LOCK CLAMP LONG ASSM BLK
1-7 881946 WHL LCK PUSH LG R W/O CLMP
1-7 881947 WHL LCK PUSH LG L W/O CLMP
1-7,12,13 882023 WHL LCK PUSH LG R W/GRADE AID
1-7,12,13 882024 WHL LCK PUSH LG L W/GRADE AID
