QUICKIE GTX PAGE 17
FROG LEG ASSEMBLY
Pos. Item Number Description Remarks
1A 050156-001 ELASTOMER FROGLEGS SOFT
1C 050156-003 ELASTOMER FROGLEGS FIRM
1B 050156-002 ELASTOMER FROGLEGS MEDIUM
2 102257 BHCS M4 X .7 X 8 INORGANIC
3 050039 CUP SPLINE ANG ADJ
4 502050 SPLINE, CASTER, ANGLE ADJ, UPPER
5 502051 SPLINE, CASTER, ANGLE ADJ, LOWER
6 050087 CASTER CAP ANGLE ADJ
7 050074 O-RING .625 ID X .125W
8 050134 SET SCREW M12 X 20MM LG FLT PT
9 050041 BARREL PIVOT ANG ADJ
10 050040 PIN PIVOT ANG ADJ
11 481398 SHCS, M12 x 1.75, ANGLE ADJ
12 265161 WASHER LOCK M12
17 050157-001 "WHL CSTR FROG LEGS 4"" X 1.5"""
17 050157-002 "WHL CSTR FROG LEGS 5"" X 1.5"""
17 050157-003 "WHL CSTR FROG LEGS 6"" X 1.5"""
13-16 050155 FORK FROG LEGS INT BRNG
1A,13-16 050225-001 FORK FROGLEGS INT BRNG SOFT
1B,13-16 050225-002 FORK FROGLEGS INT BRNG MED
1C,13-16 050225-003 FORK FROGLEGS INT BRNG FIRM
2-12 050224 SPLINE CASTER HDWR KIT
