PAGE 24 QUICKIE GTX
WHEEL LOCK (PULL-TO-LOCK)
Pos. Item Number Description Remarks
1 560500-QU HB PLASTIC COVER
3 560126 .250 ID .312 OD BUSHING PLST
4 226110 1/4-28 x 1 BH C/S
5 550374 " WHEEL LOCK SLIDE BLOCK 3 1/2"" BLK"
6 201100-QU 1/4-28 NYLOCK NUT THIN
7 561028 1/4" NYLON WASHER
8 230011 SHCS M6X 1 X 20MM TORX T-30
9 050129-001 LOCKWASHER HIGH COLLAR M6
10B 050160 CLAMP WHL LCK LNG MALE
10A 050120 CLAMP WHL LCK MALE
11B 050061 CLAMP WHL LCK LNG FEMALE
11A 050121 CLAMP WHL LCK FEMALE
12 880904 GRADE AID PLATE W/WHL R BLK
12 880905 GRADE AID PLATE W/WHL L BLK
13 483027 1/4 X 1/4 ALUM SPACER BLK
1,2 881798 WHEEL LOCK ASSM R PULL
1,2 881797 WHEEL LOCK ASSM L PULL
8-10A,11A 050229 WHEEL LOCK CLAMP ASSM BLK
8,9,10B,11B 050230 WHEEL LOCK CLAMP LONG ASSM BLK
1-7 881948 WHL LCK PULL LG R W/O CLMP
1-7 881949 WHL LCK PULL LG L W/O CLMP
1-7,12,13 882025 WHL LCK PULL LG R W/GRADE AID
1-7,12,13 882026 WHL LCK PULL LG L W/GRADE AID
