PAGE 104 QUICKIE GTX
SIDE GUARD ALUM - SEAT RAIL MOUNT
Pos. Item Number Description Remarks
1 051302 SIDEGUARD ALU LEFT
1 051303 SIDEGUARD ALU RIGHT
1 051304 SIDEGUARD ALU W/FENDER LEFT
1 051305 SIDEGUARD ALU W/FENDER RIGHT
1 051308 SIDEGARD CARBON WITH FNDR LEFT
1 051309 SIDEGARD CARBON WITH FNDR RT
2 230510 M6-25 FH C/S BLK
3 000 138 017 ROSETTE FOR M6 STEEL
4 561026 3/4" WASHER 1/4" HOLE
5 050129-001 LOCKWASHER HIGH COLLAR M6
Pos. Item Number Description Remarks
6 013157 SHCS M6 X 1 X 25 BLK W/PL
7 200113 NUT HEX NYLOCK M6 X 1
8 052176 CLAMP BACK SIDEGUARD
9 052177 CLAMP BACK TAB SIDEGUARD
10 052174 CLAMP SEAT SIDEGUARD
11 052175 CLAMP SEAT TAB SIDEGUARD
12 250104 WASHER FLAT M6
13 000 138 014 ROSETTE FOR M6 PLASTIC
14 051446-001 SIDEGUARD PROTECTION RIGHT
14 051446-002 SIDEGUARD PROTECTION LEFT
