Sunrise Medical 4 User Manual
Improving people’s lives, Warranty, Features
Warranty:
Frame - 5 years
Controller – 2 years
Motor and Gearboxes – 1 year
Specifications
TREK 3
TREK 4
Overall Length:
38"
40.5
Overall Width:
20"
20"
Per Charge Range* (Max):
Up to 10 miles
Up to 10 miles
Maximum Speed:
Up to 4
Up to 4
Turning Radius:
32"
44.5"
Total Weight Incl. Batteries:
81 lbs
90 lbs
Wheels:
(3) 2" x 7" (front & rear)
(4) 2" x 7" (front & rear)
Ground Clearance:
2 .5"
2 .5"
Battery:
12V 12Ah x 2
12V 12Ah x 2
Drive Train:
24V DC Motor
24V DC Motor
sealed mini-transaxle
sealed mini-transaxle
Battery Weight:
22 lbs
22 lbs
Battery Charger:
2 Amp (Off-Board)
2 Amp (Off-Board)
Weight Capacity:
250 lbs
250 lbs
Seat Type:
Foldable Molded Foam
Foldable Molded Foam
Standard Seat Weight:
14.5 lbs
14.5 lbs
Body Colors:
Maroon or Blue
Maroon or Blue
Heaviest Piece Weight:
22 lbs
22 lbs
Disassembly:
4 pieces
4 pieces
Features:
•
First travel scooter that disassembles with
no wires or clips.
•
Disassembles into 4 pieces with the heaviest
piece being only 22 lbs!
•
Includes both a basket and a padded vinyl
seat with flip-up arms.
•
Maximum speed of 4.0 mph
•
Drive range of up to 10 miles per charge
•
Height adjustable seat
Improving People’s Lives
Sunrise Medical
7477 East Dry Creek Parkway
Longmont, CO 80503
303.218.4600
800.333.4000
800.263.3390 Canada
2004 Sunrise Medical Inc. 07.04
479627 Rev. A
