PAGE 28 QUICKIE GTX
UNILATERAL WHEEL LOCK
Pos. Item Number Description Remarks
1 230032 M6 x 16 B/H CAP SCREW
2 501032 CLAMP CAP
3 501031 WHEEL LOCK EXTENSION
4 102262-002 BHCS M6 X 1 X 10 W/PL INORG
5 501033 REMOTE LOCK CLAMP
7 883300 1-HAND WHLLCK RLCMNT HNDL KIT
9 226112 1/4-28 x 1 SOC C/S BLK
10 262114 1/4 WASHER HI COLLAR
11A 050120 CLAMP WHL LCK MALE
11B 050160 CLAMP WHL LCK LNG MALE
12A 050121 CLAMP WHL LCK FEMALE
12B 050161 CLAMP WHL LCK LNG FEMALE
13A 341760 WHEEL LOCK CABLE SHORT 12 -14" WIDE CHAIRS
13B 341761 WHEEL LOCK CABLE MEDIUM 15 -17" WIDE CHAIRS
13C 341762 WHEEL LOCK CABLE LONG 18 -20" WIDE CHAIRS
9-11A,12A 050229 WHEEL LOCK CLAMP ASSM BLK
9-11B,12B 050230 WHEEL LOCK CLAMP LONG ASSM BLK
1-3,8A 882123 HND LOCK SUB-ASSM RIGHT SHOWN
1-3,8B 882121 HND LOCK SUB-ASSM LEFT
1-6A 882124 RMT LOCK SUB-ASSM RIGHT SHOWN
1-6B 882122 RMT LOCK SUB-ASSM LEFT
1-6A,8A 102110-001 UNILATERAL PUSH ASSY R SHORT 12 -14" WIDE CHAIRS
1-6A,8A 102110-002 UNILATERAL PUSH ASSY R MED 15 -17" WIDE CHAIRS
1-6A,8A 102110-003 UNILATERAL PUSH ASSY R LONG 18 -20" WIDE CHAIRS
